Nickel-metal hydride (Ni-Mh) batteries in hybrid vehicles
Lithium-ion (Li-ion) batteries in electric vehicles
BALANCING/DISCHARGING/CHARGING
GALVANICALLY ISOLATED CHANNELS
A FULLY AUTOMATIC PROCESS
VOLTAGE - 0.02%,CURRENT - 0.5%.
SOFTWARE UPDATE
Diagnoses high voltage battery modules, determining their capacity.
Charges sequentially connected cells of batteries that are unbalanced over time.
Prepares the battery for installation on the car by balancing all modules by voltage.
Prepares modules for storage, charging them to a certain level.
The tester MS800 (MS800A) was developed to detect faulty modules of batteries of electric vehicles. The tester allows us to determine the capacity of modules of high-voltage nickel-metal hydride (Ni-Mh) and lithium-ion (Li-Ion) batteries of hybrid cars and electric vehicles, which is the main criterion of the state of the battery module.
The tester MS800 (MS800A) was developed to detect faulty modules of batteries of electric vehicles.
The device has 36/12 galvanically isolated channels, which allows for simultaneous testing of up to 36 modules, each consisting of 3-12 Ni-mh cells.
The tester allows us to determine the capacity of modules of high-voltage nickel-metal hydride (Ni-Mh) and lithium-ion (Li-Ion) batteries of hybrid cars and electric vehicles, which is the main criterion of the state.
Measurement accuracy: voltage - 0.02%, current - 0.5%; of the battery module.
Stores all measured data during the battery module diagnostic (balancing) process in its memory. These data can then be reviewed and analyzed on a PC using the TesterLogReader software, which you can download and use for free and also print out the final report.See more real diagnostic results.
36/12 Independent galvanically isolated channels.
Automatic diagnostics and balancing processes.
Separate temperature sensor for each channel.
Full protection of battery and tester in case of incorrect connection (incorrect polarity).
The tester records all tests to an SD card inside the tester.
The control and monitoring of the diagnostic process are carried out on a touch screen.
Module protection against recharge/reboot.
Free software update.
MSG Equipment - developer and manufacturer of diagnostic equipment for automotive components, providing solutions for workshops, industrial manufacturers, and component manufacturers.
OWN R&D DEPARTMENT
We constantly maintain the relevance of our equipment through regular updating of software and databases.
PARTNER NETWORK OF SERVICE STATION
We develop equipment taking into account the recommendations, comments and wishes of practitioners.
TECHNICAL SUPPORT
We provide unlimited technical support on questions of equipment and diagnostics of units.
OWN TRAINING CENTER FOR DIAGNOSTICS AND REPAIR OF UNITS
Author training programs based on the experience of repair and restoration of units in the partner network of the Service Station, our development of repair technologies, as well as the knowledge accumulated by our specialists from all over the world.
The time required to diagnose a battery module depends on many factors and can take from several hours to several days. For example, let’s consider the check of a common battery module (lithium-ion battery) Type B Nissan Leaf ZE0 (10-12) with a nominal capacity of 60 Ah. This module has a 2S2P configuration, meaning two cells are connected in parallel and then two parallel-connected cells are connected in series, so the capacity of one cell to be diagnosed is 30 Ah. To diagnose such a module, the time required is:● for charging (before determining capacity) – 15/4.5 = 3.3 hours (assuming the module is 50% charged at the start of the diagnosis);● for discharging (determining capacity) – 30/5 = 6 hours;for charging – 30/4.5 = 6.6 hours.
In total, it takes about 16 hours to diagnose this module. Our tester can simultaneously check 18 such modules.It is important to understand one key point – accelerating the diagnostic process (reducing time) significantly increases the likelihood of module failure.
The MS800 tester has a balancing function. The tester can balance a maximum of 36 modules simultaneously.
There is no separate function for this in the tester. However, in manual mode, the tester can perform several charge/discharge cycles, which can slightly restore the cell's capacity. If a cell has lost its capacity, it cannot be restored by any means.
We do not recommend diagnosing used modules this way. Such a test is performed on new cells at the factory for rejection. For express diagnostics of the module, you can measure the internal resistance. An internal resistance meter costs about $50, similar to a good multimeter. Our tester is primarily designed to measure the capacity of cells (Ampere-hours). In a healthy battery, this value should be the same for all modules.
Printing results is done from a computer using the TesterLogReader software, which can be downloaded from the official website. Data for printing is stored in the tester's memory. This data can be copied from the tester's memory to a USB flash drive and transferred to a computer. From firmware version HMI V1.011, a brief test result can be viewed by opening the test history in the tester.
The maximum voltage on one channel is 20V, allowing the testing of any type of lithium cells, as well as NiMh modules with up to 12 series-connected cells.
Yes, but on the condition that one cell (element) with a nominal voltage of 4.2V is connected to one channel.
The main criterion for assessing the battery’s condition is the capacity of its modules. Our tester allows determining the capacity of battery modules. To determine the capacity, the following steps should be sequentially performed:1. Charge the battery modules to 100%.2. Discharge the modules to the minimum voltage for the given cell type. After the discharge is complete, the module’s capacity in Ah will be displayed on the screen.3. Charge the battery modules to 100%.
The battery is considered to be in good condition if three conditions are met:1) The capacity of the modules must be the same. Minor deviations are allowed. 2) The residual capacity of the modules must be greater than 80% of the capacity of a new module. 3) There should be no rapid self-discharge.
Yes, it can diagnose them. However, when diagnosing lithium batteries, it is important to correctly select the charge/discharge voltage. These are specified in the battery documentation. Generally, for LiPol it is 4.2V / 3.0V, for LiFePO4 it is 3.65V / 2.5V.
Important! The tester cannot discharge cells below 2.9V, but this does not hinder the diagnosis of LiFePO4 cells since the main capacity of the cell is above 2.9V. This is sufficient to check the battery on lithium iron phosphate cells.
Discharging with a low current gives a more accurate capacity measurement, which is very helpful when repairing batteries when the condition of their modules is unknown. High discharge current leads to battery heating, and high battery temperature, in turn, leads to capacity drop and can also completely disable it. Discharge currents in a car are quite high, so batteries are equipped with a thermal regulation system. Diagnostics are usually carried out without thermal regulation, so discharge currents should be lower than in a car. Moreover, the modules of a faulty battery are diagnosed, and in this case, discharging them with high currents is dangerous, especially for lithium-ion cells.
Our tester has 36 channels, they are galvanically isolated, i.e., they are not connected to each other, so two channels can be connected to one cell, thus we get 10A for discharge. However, it should be understood that in case of discharge with a current of 10A, the tester's overheat protection system may not respond in time, as it is designed for a discharge current of 5A.
